20W LED Garage Lights High Output Canopy Light Sidewalls Lighting20W LED Garage Lights High Output Canopy Light Sidewalls Lighting
Product Description
KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
Power (W)
20W
20W
20W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
2,698
2,698
2,698
Efficacy (lm/W)
137
137
137
Voltage (V)
100-277V
Power Factor
>90%
THD
<20%
CRI
≥73
Optics
UV resistant high quality lens
Beam Angle (°)
160° Std. ( 120° available)
LED Class
UL Listed: LM80
Driver Class
UL Listed: Class II
Operating Temperature(°C)
–25°C to 45°C
IP Rating
IP65
Environment
Indoor or Outdoor
Certificates
UL cUL, LM79, LM80
Controls
10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H)
150,000 hours per L70 TM-21@ 25°C
Warranty
6-year limited system warranty
Features
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming
Housing & Finish
• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Warranty
• 6-year limited system warranty
Beam Angle
120°, 160° optional, UV resistant high quality lens. (Default 160°)
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
High Output Canopy Lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
-
Read More
30W LED Gas Station Light Waterproof Canopy Light Underground Light 140lm/w30W LED Gas Station Light Waterproof Canopy Light Underground Light 140lm/w
Product Description
KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
Power (W)
30W
30W
30W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
3,737
3,737
3,737
Efficacy (lm/W)
137
137
137
Voltage (V)
100-277V (347-480V available)
Power Factor
>90%
THD
<20%
CRI
≥73
Optics
UV resistant high quality lens
Beam Angle (°)
160° Std. ( 120° available)
LED Class
UL Listed: LM80
Driver Class
UL Listed: Class II
Operating Temperature(°C)
–25°C to 45°C
IP Rating
IP65
Environment
Indoor or Outdoor
Certificates
UL cUL, LM79, LM80
Controls
10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H)
150,000 hours per L70 TM-21@ 25°C
Warranty
6-year limited system warranty
Features
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming
Housing & Finish
• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Warranty
• 6-year limited system warranty
Beam Angle
120°, 160° optional, UV resistant high quality lens. (Default 160°)
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
Waterproof Canopy Lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
-
Read More
40W LED Canopy Light Garage Light High Output Gas Station Light IP65 140lm/w40W LED Canopy Light Garage Light High Output Gas Station Light IP65 140lm/w
Product Description
KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
Power (W)
40W
40W
40W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
5,021
5,021
5,021
Efficacy (lm/W)
136
136
136
Voltage (V)
100-277V (347-480V available)
Power Factor
>90%
THD
<20%
CRI
≥73
Optics
UV resistant high quality lens
Beam Angle (°)
160° Std. ( 120° available)
LED Class
UL Listed: LM80
Driver Class
UL Listed: Class II
Operating Temperature(°C)
–25°C to 45°C
IP Rating
IP65
Environment
Indoor or Outdoor
Certificates
UL cUL, LM79, LM80
Controls
10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H)
150,000 hours per L70 TM-21@ 25°C
Warranty
6-year limited system warranty
Features
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming
Housing & Finish
• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Warranty
• 6-year limited system warranty
Beam Angle
120°, 160° optional, UV resistant high quality lens. (Default 160°)
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
High Output Gas Station Light is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
-
Read More
55W LED Canopy Fixture High Output Garage lights Entryway Lighting55W LED Canopy Fixture High Output Garage lights Entryway Lighting
Product Description
KAIWIM 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
Power (W)
55W
55W
55W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
7,165
7,165
7,165
Efficacy (lm/W)
139
139
139
Voltage (V)
100-277V (347-480V available)
Power Factor
>90%
THD
<20%
CRI
≥73
Optics
UV resistant high quality lens
Beam Angle (°)
160° Std. ( 120° available)
LED Class
UL Listed: LM80
Driver Class
UL Listed: Class II
Operating Temperature(°C)
–25°C to 45°C
IP Rating
IP65
Environment
Indoor or Outdoor
Certificates
UL cUL, LM79, LM80
Controls
10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H)
150,000 hours per L70 TM-21@ 25°C
Warranty
6-year limited system warranty
Features
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming
Housing & Finish
• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Warranty
• 6-year limited system warranty
Beam Angle
120°, 160° optional, UV resistant high quality lens. (Default 160°)
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
High Output Garage lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
-
Read More
80W LED Garage Light Fixtures LED Canopy Light Waterproof Outdoor Ceiling Lights80W LED Garage Light Fixtures LED Canopy Light Waterproof Outdoor Ceiling Lights
Product Description
KAIWIM 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
Power (W)
80W
80W
80W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
10,039
10,039
10,039
Efficacy (lm/W)
133
133
133
Voltage (V)
100-277V (347-480V available)
Power Factor
>90%
THD
<20%
CRI
≥73
Optics
UV resistant high quality lens
Beam Angle (°)
160° Std. ( 120° available)
LED Class
UL Listed: LM80
Driver Class
UL Listed: Class II
Operating Temperature(°C)
–25°C to 45°C
IP Rating
IP65
Environment
Indoor or Outdoor
Certificates
UL cUL, LM79, LM80
Controls
10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H)
150,000 hours per L70 TM-21@ 25°C
Warranty
6-year limited system warranty
Features
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Controls
• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional
Housing & Finish
• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Warranty
• 6-year limited system warranty
Beam Angle
120°, 160° optional, UV resistant high quality lens. (Default 160°)
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
High Output Garage lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
-
Read More
100w Outdoor LED Spotlight100w Outdoor LED Spotlight
Product Description
PRODUCT SPECIFICATIONS
Product name:
100w outdoor LED spotlight
Power:
100W
Working voltage:
AC90-295V, 50/60Hz
PF:
> 0.97
IP Grade:
IP65
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Light Efficiency:
105-110lm/w
View angle:
5°, 15°, 25°, 45°
CONFIGURATION
LED chip:
CREE XTE
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-30℃ to 50℃
Storage Temperature:
-30℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Dimension:
Application:
Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc. -
Read More
150w Outdoor LED Spot Light150w Outdoor LED Spot Light
Product Description
PRODUCT SPECIFICATIONS
Product name:
150w outdoor LED spot light
Power:
150W
Working voltage:
AC90-295V, 50/60Hz
PF:
> 0.97
IP Grade:
IP65
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Light Efficiency:
105-110lm/w
View angle:
5°, 15°, 25°, 45°
CONFIGURATION
LED chip:
CREE XML
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-30℃ to 50℃
Storage Temperature:
-30℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Dimension:
Application:
Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc. -
Read More
250w Outdoor LED Spot Light250w Outdoor LED Spot Light
Product Description
PRODUCT SPECIFICATIONS
Product name:
250w outdoor LED spot light
Power:
250W
Working voltage:
AC90-305V, 50/60Hz
PF:
> 0.97
IP Grade:
IP65
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Light Efficiency:
105-110lm/w
View angle:
6°, 10°, 20°, 30°, 60°
CONFIGURATION
LED chip:
CREE XTE
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-30℃ to 50℃
Storage Temperature:
-30℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Dimension:
Application:
Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc. -
Read More
500w Outdoor LED Spot Light500w Outdoor LED Spot Light
Product Description
PRODUCT SPECIFICATIONS
Product name:
500w outdoor LED spot light
Power:
500W
Working voltage:
AC90-305V, 50/60Hz
PF:
> 0.97
IP Grade:
IP65
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Light Efficiency:
105-110lm/w
View angle:
6°, 10°, 20°, 30°, 60°
CONFIGURATION
LED chip:
CREE XML
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-30℃ to 50℃
Storage Temperature:
-30℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Dimension:
Application:
Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc. -
Read More
80w explosion proof led lighting for gas station80w explosion proof led lighting for gas station
Product Description
Product Name: 80w explosion proof LED lighting for gas station
With Philips LED, Mean Well driver, 5 years warranty
Specifications:
Product name:
80w Explosion proof led lighting
Power:
80W
Working voltage:
AC90-295V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
115-120LM/W
CONFIGURATIONS
LED chip:
96pcs Philips LED
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
White
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Net Weight:
4.5 KGS
Gross Weight:
5.5 KGS
Packing Size:
40*40*20CM
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Size of 80w explosion proof led lighting:
Application:
Gas station, shop, warehouse, indoor sports stadium with ceiling, etc. -
Read More
120w LED Gas Station canopy lights120w LED Gas Station canopy lights
Product Description
Product Name: 120w LED gas station canopy lights
With Philips LED, Mean Well driver, 5 years warranty
Specifications:
Product name:
120w LED gas station canopy lights
Power:
120W
Working voltage:
AC90-295V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
115-120LM/W
CONFIGURATIONS
LED chip:
144pcs Philips LED
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
White
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Net Weight:
5.5 KGS
Gross Weight:
6.5 KGS
Packing Size:
40*40*20CM
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Size of 120w LED gas station canopy lights:
Application:
Gas station, shop, warehouse, indoor sports stadium with ceiling, etc. -
Read More
150w explosion proof LED canopy lights150w explosion proof LED canopy lights
Product Description
Product Name: 150w Explosion Proof LED canopy lights
With Philips LED, Mean Well driver, 5 years warranty
Specifications:
Product name:
150w explosion proof led canopy lights
Power:
150W
Working voltage:
AC90-295V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
115-120LM/W
CONFIGURATIONS
LED chip:
192pcs Philips LED
LED driver:
Mean Well
Heat sinks:
Aluminum
Body color:
White
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Net Weight:
7.0 KGS
Gross Weight:
8.5 KGS
Packing Size:
40*50*20CM
Warranty:
5 Years
Certificates:
CE, RoHS, FCC
Product Size of 150w explosion proof LED canopy lights:
Application:
Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
