Feature / Warranty



Because of its advantages of stable quality and good price, also they could meet customers' basic need,
the SMD3528 strips are always the classic choice in the market.


IP rate


Aluminum Profiles



Electrical & Output Data





Step length (mm/x LED)
25mm/6LEDs
50mm/12LEDs


Number LED/m
240
240


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
15.2
15.2


FPC width (mm)
15
15


Max. length per circuit (m)
5
5


IP rate
20
20


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
88lm/W @Ra80
75.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 1070lm
 1012lm


2500K
 1271lm
 1305lm


2700K
 1311lm
 1119lm


3000K
 1338lm
 1150lm


3500K
 1338lm
 1173lm


4000K
 1364lm
 1208lm


5000K
 1271lm
 1208lm


6000K
 1271lm
 1206lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







Because of its advantages of stable quality and good price, also they could meet customers' basic need,
the SMD3528 strips are always the classic choice in the market.



IP rate








Aluminum Profiles






    1616









        1708







             2308






Electrical & Output Data





Step length (mm/x LED)
25mm/3LEDs
50mm/6LEDs


Number LED/m
120
120


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
7.6
7.6


FPC width (mm)
8
8


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
88lm/W @Ra80
75.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 535lm
 506lm


2500K
 635lm
 518lm


2700K
 665lm
 560lm


3000K
 669lm
 575lm


3500K
 669lm
 578lm


4000K
 682lm
 604lm


5000K
 635lm
 604lm


6000K
 635lm
 605lm





Dimensions & available lengths



Illuminance Distribution





Feature / Warranty







Because of its advantages of stable quality and good price, also they could meet customers' basic need,
the SMD3528 strips are always the classic choice in the market.



IP rate








Aluminum Profiles






    1616









        1708







           2308






Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
3.8
3.8


FPC width (mm)
8
8


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
88lm/W @Ra80
75.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 268lm
 253lm


2500K
 318lm
 259lm


2700K
 328lm
 280lm


3000K
 334lm
 288lm


3500K
 334lm
 293lm


4000K
 341lm
 302lm


5000K
 318lm
 302lm


6000K
 318lm
 302lm





Dimensions & available lengths



Illuminance Distribution
