Product Description
KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.
Specification Summary
| Power (W) | 20W | 20W | 20W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 2,698 | 2,698 | 2,698 |
| Efficacy (lm/W) | 137 | 137 | 137 |
| Voltage (V) | 100-277V | ||
| Power Factor | >90% | ||
| THD | <20% | ||
| CRI | ≥73 | ||
| Optics | UV resistant high quality lens | ||
| Beam Angle (°) | 160° Std. ( 120° available) | ||
| LED Class | UL Listed: LM80 | ||
| Driver Class | UL Listed: Class II | ||
| Operating Temperature(°C) | –25°C to 45°C | ||
| IP Rating | IP65 | ||
| Environment | Indoor or Outdoor | ||
| Certificates | UL cUL, LM79, LM80 | ||
| Controls | 10KA Surge Protection, Dimming, Sensors, Emergency back-up available | ||
| Life (L70, H) | 150,000 hours per L70 TM-21@ 25°C | ||
| Warranty | 6-year limited system warranty | ||
Features• High system efficacy up to 142 LPW |
Controls• 0-10V dimming optional |
Electrical• 100-277V, and 347-480V available |
Housing & Finish• Die-casting aluminum heat sink |
Ratings• 150,000 hours per L70 TM-21@ 25°C |
Compliance• DLC Premium |
Warranty• 6-year limited system warranty |
Beam Angle120°, 160° optional, UV resistant high quality lens. (Default 160°) |
Installation Options
Ceiling mount, pendant mount and quick plate mount available.
Quick Plate Mount
Pendant Mount
Ceiling Mount
Advantages of Gen.6 Canopy Light
• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents
Applications
• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc
High Output Canopy Lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
