3014LED Strips

  • Read More

    3014-120-6mm-5m(Side View LEDs)

    Feature / Warranty



    ◆ Top View SMD3014 strips have better performance in linear light.
    ◆ Because of its advantages of stability and high brightness,
    SMD3014side view strips are perfect replacement of SMD335 strips.


    IP rate




    Electrical & Output Data





    Step length (mm/x LED)
    25mm/3LEDs
    25mm/6LEDs


    Number LED/m
    120
    120


    Voltage (v)
    12V
    24V


    Ra
    80
    80


    Beam Angle(º)
    120
    120


    Power (w/m)
    10
    10


    FPC width (mm)
    6
    6


    Max. length per circuit (m)
    5
    5


    IP rate
    20/66/68
    20/66/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    83lm/W @Ra80


    LED color
    Ra80


     = Popular Color
     = Special Color


    2700K
     797lm


    3000K
     830lm


    4000K
     896lm


    6000K
     896lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    3014-60-6mm-5m(Side View LEDs)

    Feature / Warranty



    ◆ Top View SMD3014 strips have better performance in linear light.
    ◆ Because of its advantages of stability and high brightness,
    SMD3014side view strips are perfect replacement of SMD335 strips.


    IP rate




    Electrical & Output Data





    Step length (mm/x LED)
    50mm/3LEDs
    100mm/6LEDs


    Number LED/m
    60
    60


    Voltage (v)
    12V
    24V


    Ra
    80
    80


    Beam Angle(º)
    120
    120


    Power (w/m)
    5
    5


    FPC width (mm)
    6
    6


    Max. length per circuit (m)
    5
    5


    IP rate
    20/66/68
    20/66/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    83lm/W @Ra80


    LED color
    Ra80


     = Popular Color
     = Special Color


    2700K
     398lm


    3000K
     415lm


    4000K
     448lm


    6000K
     448lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    3014-120-8mm-5m

    Feature / Warranty







    ◆ Top View SMD3014 strips have better performance in linear light.
    ◆ Because of its advantages of stability and high brightness,
    SMD3014side view strips are perfect replacement of SMD335 strips.




    IP rate







    Aluminum Profiles





        1616









             1708







                2308








    Electrical & Output Data





    Step length (mm/x LED)
    25mm/3LEDs
    50mm/6LEDs


    Number LED/m
    120
    120


    Voltage (v)
    12V
    24V


    Ra
    80
    80


    Beam Angle(º)
    120
    120


    Power (w/m)
    11.52
    11.52


    FPC width (mm)
    8
    8


    Max. length per circuit (m)
    5
    5


    IP rate
    20/65/66/67/68
    20/65/66/67/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80


    LED color
    Ra80


     = Popular Color
     = Special Color


    2700K
     955lm


    3000K
     1037lm


    4000K
     1120lm


    6000K
     1120lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    3014-60-8mm-5m

    Feature / Warranty







    ◆ Top View SMD3014 strips have better performance in linear light.
    ◆ Because of its advantages of stability and high brightness,
    SMD3014side view strips are perfect replacement of SMD335 strips.




    IP rate




    Aluminum Profiles





         1616









            1708







               2308








    Electrical & Output Data



    Step length (mm/x LED):50mm/3LEDs
    Number LED/m:60
    Voltage (v):12V
    Ra:80
    Beam Angle(º):120
    Power (w/m):5.76
    FPC width (mm):8
    Max. length per circuit (m):5
    IP rate:20/65/66/67/68
    Installation:3M Tape / Mounting Clips / Aluminum Pro?les



    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80


    LED color
    Ra80


     = Popular Color
     = Special Color


    2700K
     498lm


    3000K
     518lm


    4000K
     560lm


    6000K
     560lm





    Dimensions & available lengths



    Illuminance Distribution
